Product Description
High Bay LED Luminaire CL-2282 Industrial LED High Bay Fixture, suitable for wet locations, designed to mount on ceilings up to 20 ft. Heights in Factories, Found-ries, Machines Shops, Warehouse, Large Retail Stores, Gymnasiums and Indoor Sport Arenas. This fixture has a wide light distribution.10 Year / 100,000 Hour Limited Warranty.
Features :
- Energy Savings : Over 66% compared to HID light sources.
- Improved lumen maintenance.
- High efficient Lumiled LED’s.
- Operating temperatures : -30°C ~ 60°C.
- Driver : Constant current, 120-277v, 50/60Hz, 480v (Optional).
- Suitable for Wet Locations.
- Options : Occupancy Sensors or Wireless Controls.
- Operating Life : >60,000 hours
Construction:
- Heavy-Duty Aluminum Spun Housing.
- 3 Mill Powder Coat Finish, (Various colors available) (Custom).
- Conical Drop Lens or Prismatic Drop Lens (Optional)
- Silicone Gasket to prevent leakage and provide IP-66 Rated Product. •Mounting: Hook (Standard) or 3/4” Threaded HUB (Optional)
Cat # : CL-2282-S
- Wattage : 50W (50CLED)
- Color Temp : 3000K (30K)
- Voltage : 120-277V (MV)
- Color : Black (BLK)
- Mounting : Hook (HK)
- Options : Motion Sensor (OCC)
Cat # : ———-
- Wattage : 75W (75CLED)
- Color Temp : 4000K (40K)
- Voltage : 480V (HV)
- Color : White (WH)
- Mounting : 3/4 HUB (34H)
- Options : Wireless Control (WC)
Cat # : CL-2282-L
- Wattage : ----------
- Color Temp : 5000K (50K)
- Color : Bronze (BRZ)
- Options : Conical Drop Lens (CDL)
Wattage : 100W (100CLED)
Color : Silver (SIL)
Options : Prismatic Drop Lens (PDL)
Wattage : 120W (120CLED)
Color : Graphite (GPH)Wattage : 150W (150CLED)
Color : Custom (CST)Dimensions :Cat# : CL-2282-S
- A : 10” 1/2
- B : 16” 1/4
- C : 22” 1/4
- A : 13” 3/8
- B : 22” 1/4
- C : 25”
- Input Power : 85W
- Lumen Output : 9,097
- LPW : 181
- Color Temp.(CCT) : 5000K
- CRI : 70+
- Rated Life (L70) : >200,000
- Imput Voltage : 120-277V
- HID Equivalent : 50/60HZ
- HID Equivalent : 210W MH
Cat # : CL-2282-S-75CLED
- Input Power : 80W
- Lumen Output : 11,784
- LPW : 157
- Color Temp.(CCT) : 5000K
- CRI : 70+
- Rated Life (L70) : >200,000
- Imput Voltage : 120-277V
- HID Equivalent : 50/60HZ
- HID Equivalent : 250W MH
- Input Power : 105W
- Lumen Output : 16,834
- LPW : 168
- Color Temp.(CCT) : 5000K
- CRI : 70+
- Rated Life (L70) : >200,000
- Imput Voltage : 120-277V
- HID Equivalent : 50/60HZ
- HID Equivalent : 250W MH
- Input Power : 125W
- Lumen Output : 20,201
- LPW : 168
- Color Temp.(CCT) : 5000K
- CRI : 70+
- Rated Life (L70) : >200,000
- Imput Voltage : 120-277V
- HID Equivalent : 50/60HZ
- HID Equivalent : 400W HPS
Cat # : CL-2282-L-150CLED
- Input Power : 155W
- Lumen Output : 23,346
- LPW : 155
- Color Temp.(CCT) : 5000K
- CRI : 70+
- Rated Life (L70) : >200,000
- Imput Voltage : 120-277V
- HID Equivalent : 50/60HZ
- HID Equivalent : 400W HPS
